Luxaire® ZV-A4E20P2D6BAA1A1 1084752

Delivering heating and cooling equipment you can trust requires an uncompromising approach to quality. Through innovative processes and rigorous testing, each Luxaire unit is built to provide consistently dependable comfort.

Luxaire® Single Packaged Rooftop Electric/Electric Air Conditioner Unit, Series: Ovation, Model: ZV-A4, 51200 MBH Gross Cooling, 50000 MBH Net Cooling Input BTU, 208/230 VAC, 3.57 kW Cooling, 20 kW Heating Wattage, 1-1/2 hp Evaporator, 1/3 hp Condenser, 1725 rpm Evaporator, 850 rpm Condenser Rotational Speed, 60 Hz, 3 ph Phase, (1) 2-Stage Scroll Compressor, Evaporator Coil - 10.56 sq-ft Face Area, 15 Fins/in, Condenser Coil - 12.2 sq-ft Face Area, 23 Fins/in, 1600 cfm, 14 EER Rating, 17.5 SEER, 4 ton Tonnage, 2 Heat/Cool Stages, R-410A Refrigerant, 75 dBA Decibel Rating, Belt Drive Evaporator, Direct Drive Condenser Drive, 1 in NPT Drain Connection, (4) 24 x 16 x 2 in Filter, Steel, Galvanized, Powder-Painted, 89 in L x 59 in W x 42 in H

• Easy to install - Uses MicroChannel condenser coils in a two-stage packaged cooling and heating rooftop line
• Flexibility - Enjoy the flexibility of a single footprint to fit most applications
• Durability - feel confident with built-in protections and certified safeties
• 5 years limited compressor warranty
• 5 years limited electric heat warranty
• 10 years limited heat exchanger warranty
• 1 year limited parts warranty (Warranty terms vary based on product registration and model details)
• 5 year electric heat warranty (Warranty terms vary based on product registration and model details)
• VFD intellispeed standard static blower
• Economizer with power exhaust
• DSC (disconnect switch), PCO (powered convenience outlet)
• Stand alone smart equipment
• PHM (phase monitor)
• Standard refrigeration
• Standard cabinet
• Standard throwaway filter
• First generation

• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Luxaire_ZV_A3N06P2B4HMA1A2_Catalog.pdf
• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Luxaire_ZV_A5N08P2B6NAB4A1_Specification_Sheet.pdf
