Honeywell T775A1001 1067578

The T775 family of electronic remote temperature controllers provide on/off, modulating or reset control in applications where electronic accuracy in addition to remote sensing is desired.

Honeywell Temperature Controller, Model: T775, 24/240/120 VAC, Platinum Sensor Sensor, SPDT, +/-1 deg F at 77 deg F Accuracy, Platinum Sensor Sensing Element, 50/60 Hz Frequency, 10 A at 24 VAC Resistive, 9.8 AFL, 58.8 ALR at 1250 VAC, 125 VA Pilot Duty Contact, LCD Display, 1 to 35 deg F Differential, Temperature Settings: -40 to 220 deg F, 2-3/8 in Length, 8-1/2 in Height, 4-3/4 in Width, NEMA 4X Enclosure, Up to 1000 ft Measuring, -40 to 140 deg F

• Typical applications includes - on/off control of fans, motors and heaters, proportional and floating control of damper and valve actuators, outdoor reset of heating and cooling systems
• Electronic control accuracy
• Linear platinum temperature sensor, LCD display indicates mode and output status, jumper switch provides field selection of F or C display
• Keypad allows precise temperature selection, easy one finger programming
• Remote sensing from up to 1000 ft
• Wide temperature setting range
• Adjustable differential and throttling range
• Heating and cooling stages independently programmable
• Available with one or two temperature inputs and up to four SPDT relay output stages or modulating (electronic Series 90, 4 to 20 mA or 0 to 18 VDC) outputs

• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Honeywell_T775A1001_Catalog.pdf
• Instruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Honeywell_T775A1001_Instruction_Installation_Manual.pdf
