Carrier® Temperature Control, 24 VAC External Source, 24 VDC Power Module, 50/60 Hz, LED Display, Temperature Settings: -30 to 130 deg F, DIN Rail Mounting, High Impact Thermoplastic Cover, NEMA 1 Enclosure, 3.2 V-A Maximum Power Consumption, -30 to 150 deg F
| Display Type | : | LED |
| Enclosure Type | : | NEMA 1 |
| Frequency Rating | : | 50/60 Hz |
| Material | : | High Impact Thermoplastic Cover |
| Mounting Type | : | DIN Rail |
| Power Consumption | : | 3.2 V-A Maximum |
| Temperature Rating | : | -30 to 150 deg F |
| Temperature Settings | : | -30 to 130 deg F |
| Voltage Rating | : | 24 VAC External Source, 24 VDC Power Module |
- The A350P is an electronic, proportional plus integral temperature control with analog 0 - 10 VDC and 0 - 20 mA outputs
- The control is equipped with 3-user selectable time integration constants
- The A350P control is housed in a NEMA 1, high-impact plastic enclosure
- The modular design provides easy, plug-together connections for quick installation and future expandability
- Modular design
- Plug-together connectors and 35 mm DIN rail mounting
- 0 - 60% minimum output adjustable
- 2 - 30 deg F throttling range
- Field selectable secondary drain location
- Interchangeable temperature sensors
- Includes A99BC-25C sensors
