Goodman® CPG2404003BXXX 1033774
Goodman® CPG CPG2404003BXXX Packaged Gas/Electric Unit, 240000 Btu/hr Cooling, 400000 Btu/hr Heating Input BTU, 95 A
- Manufacturer: Daikin Comfort Technologies
- Brand Name: Goodman®
- Part Number: 1033774
- MPN: CPG2404003BXXX
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Goodman® Packaged Gas/Electric Unit, Series: CPG, 240000 Btu/hr Cooling, 400000 Btu/hr Heating Input BTU Rating, 208 - 230 VAC, 95 A, 5 hp Evaporator Motor, 1/3 hp Condenser Motor, 1725 rev/min Evaporator Motor, 1075 rev/min Condenser Motor, 60 Hz, 3 -Phase, (2) Scroll Compressor, Configuration: Evaporator Coil - 20 sq-ft Face Area, 16 Fins/in, Condenser Coil - 53.3 sq-ft Face Area, 18 Fins/in, 7000 cu-ft/min Evaporator Motor, 7200 cu-ft/min Condenser Motor, 10 IEER Rating, 9.8 EER, 80% Steady State AFUE, 20 ton, 8 -Burner, R-410A Refrigerant, 88.3 dBA Decibel Rating, Belt Drive, 1 in NPT Drain Connection, (6) 25 x 25 x 2 in Filter, 125 A Fuse, Heavy Gauge Steel, Galvanized, Powder-Painted, 25 - 55 deg F High, 15 - 45 deg F Low, 50-9/32 in H x 133-1/2 in W x 88-7/32 in D
| AFUE Rating | : | 80% Steady State |
| Amperage Rating | : | 95 A |
| CFM Rating | : | 7000 cu-ft/min Evaporator Motor, 7200 cu-ft/min Condenser Motor |
| Compressor Type | : | (2) Scroll |
| Configuration | : | Evaporator Coil - 20 sq-ft Face Area, 16 Fins/in, Condenser Coil - 53.3 sq-ft Face Area, 18 Fins/in |
| Connection Type | : | 1 in NPT Drain |
| Decibel Rating | : | 88.3 dBA |
| Dimensions | : | 50-9/32 in H x 133-1/2 in W x 88-7/32 in D |
| Drive Type | : | Belt |
| EER Rating | : | 9.8 |
| Filter Size | : | (6) 25 x 25 x 2 in |
| Finish | : | Galvanized, Powder-Painted |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 125 A |
| HP Rating | : | 5 hp Evaporator Motor, 1/3 hp Condenser Motor |
| IEER Rating | : | 10 |
| Input BTU Rating | : | 240000 Btu/hr Cooling, 400000 Btu/hr Heating |
| Material | : | Heavy Gauge Steel |
| Number of Burners | : | 8 |
| Phase | : | 3 |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 1725 rev/min Evaporator Motor, 1075 rev/min Condenser Motor |
| Series | : | CPG |
| Temperature Rating | : | 25 - 55 deg F High, 15 - 45 deg F Low |
| Tonnage | : | 20 ton |
| Voltage Rating | : | 208 - 230 VAC |
- Factory installed standard aluminized heat exchanger
- 33.3 A-rated load, 239 A locked rotor - compressor, 12.7 A full load blower fan, 2.4 A-rated load, 5.2 A full load - outdoor fan
- 2-1/8 in entrance power supply and 7/8 in entrance control voltage
- R-410A chlorine-free refrigerant
- TuffTube tubular heat exchanger
- High-efficiency scroll compressor
- Copper tube/aluminum fin coils
- Contactor with lugs
- High-capacity, steel-cased filter drier
- High/low pressure switches
- 24 V terminal strip
- Easy to service
- Built-in filter rack with standard 2 in filters
- Bottom utility entry
- Complies with California NOx emissions standards
- Full perimeter rail
- Sloped drain pan
- 20 years heat exchanger, five-years parts limited warranty
Specification Sheet
