Fieldpiece ATH4 1098446

The Fieldpiece Dual-Temperature Accessory, model ATH4, measures two temperatures simultaneously using the included k-type, wrap tab beaded thermocouples. The technology inside the ATH4 provides superior temperature compensation in rapidly changing environments commonly found while performing field service. Use the ATH4 to find Delta T and just about any temperature split you want to measure. Displays T1, T2 and T1-T2 on your Fieldpiece meter, handle or data logger. It is included with the HVAC Guide System Analyzer to get target superheat and for the Target Evaporator Exit Temperature test. Fieldpiece offers a wide variety of k-type thermocouples for various HVAC specific applications. Use pipe clamp T/Cs with the ATH4 to check for blocked filters. Use wet and dry bulb thermocouples to find target superheat.

Fieldpiece Dual Temperature Accessory Head, For Use With: T1, T2 or T1-T2 Displays, 0.1 deg F Resolution, +/-1 deg F Accuracy

• Accepts any K-type thermocouple
• External calibration pots make field calibration a breeze
• Superior temperature compensation in rapidly changing environments
• Displays deg F directly at 0.1 deg F resolution on DMM with 0.1 mVDC resolution
• Converts from -50 to 1800 deg F (optional thermocouple required for 1800 deg F)
• Auto-off can be disabled for data logging

• Instruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Fieldpiece_ATH4_Manual.pdf
