Rheem®_DEL_2024_MAR_19_11_57_08 W95TC1151524MSA 1091806

Rheem® WeatherKing Gas Furnace, Series: W95T, 112000 Btu/hr Input BTU Rating, 115 VAC, 14 A, 1748 cu-ft/min Cooling, 1524 cu-ft/min Heating, 1 hp, 95% AFUE, 32.82 kW, 1 -Phase, 60 Hz, Configuration: Multi-Position, 1/2 in NPT Connection, Natural Gas Fuel, 5 -Speed, 11 in W x 11 in Dia Blower Size, 24-1/2 in W x 34 in H x 29-5/8 in D Cabinet Dimensions, X-13 (Constant Torque) Motor, Up to 5 ton, Direct Spark Ignition, 45 - 75 deg F Rise

• Four way multi-poise design
• Constant torque electrically commutated motor
• Seven segment LED all units
• Direct spark ignition for reliability and longevity
• Water management system
• Heat exchanger is removable for improved serviceability, aluminized steel primary and stainless steel secondary construction provide maximum corrosion-resistance and thermal fatigue reliability
• Low profile 34 in cabinet ideal for space constrained installations
• Blower shelf design - serviceable in all furnace orientations
• Pre marked hoses insures proper system drainage
• Vent with 2 or 3 in PVC
• Replaceable collector box
• Hemmed edges on cabinet and doors
• Quarter turn fasteners for tool less access
• Integrated control boards feature dip switches for easy system set up
• Self priming condensate trap
• 3rd design Series
• Revision marketing (first time release)

• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Rheem_W95TC0601317MSA_Specification_Sheet.pdf
