Rheem® Electric Heat Package Unit, Series: RKNL, Classic, Model: A060DL10E, 60000 Btu/hr Cooling, 100000 Btu/hr Heating Input BTU, 460 VAC, 13 A, 17.58 kW Cooling Wattage, 1/3 hp Outdoor Fan, 1/2 hp Indoor Fan, 1075 rpm Outdoor Fan, 1725 rpm Indoor Fan Rotational Speed, 60 Hz, 3 ph Phase, (1) Scroll Compressor, 2000 cfm, 11.1 EER Rating, 13 SEER, 5 ton Tonnage, 5 Burners, 1 Stage, R-410A, HFC Refrigerant, 78 dBA Decibel Rating, Electric Ignition, Belt Drive, Outdoor Coil - 16.56 sq-ft Face Area, 22 Fins/in, Indoor Coil - 5.17 sq-ft Face Area, 15 Fins/in Coil Rating, 3/4 in Drain Connection, (1) 1 x 16 x 25 in Filter, Steel, G90 Galvanized, Powder-Painted, 125 deg F Ambient, 75-17/32 in L x 46-1/2 in W x 35 in H

• Complete factory charged, wired and run tested
• Scroll compressors with internal line break overload and high-pressure protection
• Convertible air flow
• TXV refrigerant metering device
• High pressure and low pressure/loss of charge protection standard on all models
• Solid core liquid line filter drier
• One-slab, single pass designed evaporator and condenser coils facilitate easy cleaning for maintained high efficiencies
• Easily removable filter, blower, gas heat and compressor/control access panels permits prompt service
• Powder paint finish meets ASTMB117 steel-coated on each side for maximum protection, G90 galvanized
• One-piece top cover and one-piece base pan with drawn supply and return opening for superior water management
• Externally mounted refrigerant gauge ports for easy service diagnostics
• Easy to install plug-in, slip-in, 100% fully modulating economizer
• Forkable base rails for easy handling and lifting, one-point electrical and gas connections
• High performance belt drive motor with variable pitch pulleys and quick adjust belt system
• Permanently lubricated evaporator, condenser and gas heat inducer motors
• Condenser motors are internally protected, totally enclosed with shaft down design
• Condenser motors are internally protected, totally enclosed with shaft down design, 2 in filter standard with slide-out design
• Two-stage gas valve, direct spark ignition and induced draft for efficiency and reliability
• Tubular heat exchanger for long life and induced draft for efficiency and reliability
• Solid-state furnace control with on board diagnostics
