Ducane™ Package Gas Electric Unit, Series: PRGE14, Model: PRGE1430-072P, 28400 Btu/hr Cooling, 72000 Btu/hr Heating Input BTU, 58400 Btu/hr Heating Output BTU, 208/230 VAC, 18.7 A, 1/6 hp Condenser, 1/4 hp Blower Motor, 60 Hz, 1 ph Phase, 1000 cfm, 11 EER Rating, 14 SEER, 0.81 AFUE, 2.5 ton Tonnage, R-410A Refrigerant, 78 dBA Decibel Rating, Steel, Textured Pre-Painted, 40 to 70 deg F, 46.77 in W x 46.8 in D x 36.82 in H
| AFUE Rating | : | 0.81 |
| Amperage Rating | : | 18.7 A |
| CFM Rating | : | 1000 cfm |
| Decibel Rating | : | 78 dBA |
| Dimensions | : | 46.77 in W x 46.8 in D x 36.82 in H |
| EER Rating | : | 11 |
| Finish | : | Textured Pre-Painted |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/6 hp Condenser, 1/4 hp Blower Motor |
| Input BTU Rating | : | 28400 Btu/hr Cooling, 72000 Btu/hr Heating |
| Material | : | Steel |
| Model | : | PRGE1430-072P |
| Output BTU Rating | : | 58400 Btu/hr Heating |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 14 |
| Series | : | PRGE14 |
| Temperature Rating | : | 40 to 70 deg F |
| Tonnage | : | 2.5 ton |
| Voltage Rating | : | 208/230 VAC |
- Copper tubing with enhanced fin coils
- Aluminized tri-dimple tubular heat exchanger for increased efficiency
- Pest protected flue outlet
- Rounded corners for safety and an attractive, clean appearance
- One-piece base design for strength and stability
- Drain ports for condensate management and coil runoff
- Insulation to minimize heat loss plus reduce sound
- Superior service access to components
- Efficient two-speed motor for wide air flow range
- Slide-out blower housing for easy service
- Solid-state integrated blower control board with LED self-diagnostics
- Horizontal or down discharge capable
- Tabbed duct flanges for simple duct connection
- 10 years limited parts and compressor warranty and lifetime heat exchanger warranty
- 30 A fuse rating
