Amana® APG1448100M41 1095621
  1. pin-int

Amana® APG1448100M41 1095621

Amana® APG1448100M41 Packaged Gas/Electric Unit, 23000 to 57500 Btu/hr Cooling, 100000 Btu/hr Heating Input BTU, 32 A

  • Manufacturer: Daikin Comfort Technologies
  • Brand Name: Amana®
  • Part Number: 1095621
  • MPN: APG1448100M41
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Availability

Amana® Packaged Gas/Electric Unit, Series: APG14M, 23000 to 57500 Btu/hr Cooling, 100000 Btu/hr Heating Input BTU Rating, 208 to 230 VAC, 32 A, 3/4 hp Blower Motor, 1/4 hp Condenser Motor, 1050 rpm Blower Motor, 1075 rpm Condenser Motor Rotational Speed, 60 Hz, 1 ph, Scroll Compressor, Multi-Position, 1570 cfm Cooling and Heating CFM Rating, 11 EER Rating, 14 SEER, 0.81 AFUE Rating, 4 ton, 1 Stage, R-410A Refrigerant, 80 dBA Decibel Rating, NPT Connection, 50 A Fuse Rating, Powder-Painted, Gray, 52 in L x 48 in W x 44 in H

AFUE Rating      :      0.81
Amperage Rating      :      32 A
CFM Rating      :      1570 cfm Cooling and Heating
Color      :      Gray
Compressor Type      :      Scroll
Configuration      :      Multi-Position
Connection Type      :      NPT
Decibel Rating      :      80 dBA
Dimensions      :      52 in L x 48 in W x 44 in H
EER Rating      :      11
Finish      :      Powder-Painted
Frequency Rating      :      60 Hz
Fuse Rating      :      50 A
HP Rating      :      3/4 hp Blower Motor, 1/4 hp Condenser Motor
Input BTU Rating      :      23000 to 57500 Btu/hr Cooling, 100000 Btu/hr Heating
Number of Stages      :      1
Phase      :      1 ph
Refrigerant Type      :      R-410A
Rotational Speed      :      1050 rpm Blower Motor, 1075 rpm Condenser Motor
SEER Rating      :      14
Series      :      APG14M
Tonnage      :      4 ton
Voltage Rating      :      208 to 230 VAC
  • Heavy-duty stainless steel heat exchanger
  • High-efficiency compressor
  • All aluminum evaporator coils
  • Aluminum tube and aluminum fin coil construction
  • Two-speed ECM indoor blower motor
  • Redundant gas valve with easy conversion to propane
  • Power-assisted combustion
  • Direct spark ignition system includes a microprocessor based control for the entire ignition sequence, all blower operation and all safety circuits complete with self-diagnostics
  • High-quality UV-resistant powder-paint finish
  • Horizontal or down flow applications
  • Convenient access panels cabinet
  • One-roof curb fits all units cabinet
  • Fully insulated cabinet
  • Bottom, 2 in high base rails for easy handling cabinet
  • When properly anchored, meets the 2010 Florida building code unit integrity requirements for hurricane-type winds
  • All models comply with California low NOx emission standards
  • 20 years heat exchanger, five-years parts limited warranty
  • Flowrater expansion device on 2 - 4 ton units
  • Compressor sound blanket cabinet
  • Aluminum foil-facing internal insulation reinforced with fiberglass scrim cabinet
