Rosemount 2051CG2A02A1AS5KBM5Q4Q8A0078/0305RC22B11B4 1118392
Rosemount Coplanar™ 2051CG2A02A1AS5KBM5Q4Q8A0078/0305RC22B11B4 Gauge Pressure Transmitter, 225 m Wireless
- Manufacturer: Emerson Electric Co
- Brand Name: Rosemount
- Part Number: 1118392
- MPN: 2051CG2A02A1AS5KBM5Q4Q8A0078/0305RC22B11B4
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
The Rosemount 2051 Coplanar™ pressure transmitter is industry standard for differential and gage measurements. This safety certified transmitter features a local operator interface with easy-to-use menus and built-in configuration buttons, allowing you to easily commission the device. Engineered with the patented coplanar technology, this device offers installation flexibility for integrated flow or level solutions. With optional WirelessHART® technology, you can add measurement points fast, even in remote and hard to reach locations.
Rosemount Gauge Pressure Transmitter, 2051 Series, -250 to 250 in-WG Range, 4 to 20 mA Outputs, NPT Connection, +/-0.05 % Accuracy, 2000 psi, IP66, IP68, NEMA 4X Enclosure, 0 to 100 % Humidity Rating, 250 Ohm Loop Resistance, 130 ms Response, +/-0.125% of URL per 5 years Stability, 10.5 to 42.4 V, 225 m Wireless Range, Aluminum, 7.04 in H x 6.53 in W, -40 to 185 deg F
| Accuracy | : | +/-0.05 % |
| Connection Type | : | NPT |
| Dimensions | : | 7.04 in H x 6.53 in W |
| Enclosure Type | : | IP66, IP68, NEMA 4X |
| Humidity Rating | : | 0 to 100 % |
| Loop Resistance | : | 250 Ohm |
| Material | : | Aluminum |
| Outputs | : | 4 to 20 mA |
| Pressure Rating | : | 2000 psi |
| Range | : | -250 to 250 in-WG |
| Response Time | : | 130 ms |
| Series | : | 2051 Series |
| Stability | : | +/-0.125% of URL per 5 years |
| Temperature Rating | : | -40 to 185 deg F |
| Voltage Rating | : | 10.5 to 42.4 V |
| Wireless Range | : | 225 m |
- Patented Coplanar™ technology allows direct mounting for flow and level solutions that provide installation flexibility
- Delivered fully assembled to manifolds, diaphragm seals or primary flow elements for straightforward installation
- Local operator interface offers easy-to-use menus and built-in configuration buttons for streamline commissioning
- SIL 2/3 certified to IEC 61508 (via third party) and prior use certificate of FMEDA data for safety installations
- Several primary elements provide a flow solution that is factory leak tested and calibrated to simplify installation
- WirelessHART® technology is secure and cost-effective and delivers >99% data reliability
- SmartPower™ module provides up to 10 years maintenance-free operation and field replacement without transmitter removal
- Easy installation enables quick-instrumentation of measurement points without the cost of wiring
