Luxaire® ZS-15N40B2A6BAA4A1 1055835

Delivering heating and cooling equipment you can trust requires an uncompromising approach to quality. Through innovative processes and rigorous testing, each Luxaire unit is built to provide consistently dependable comfort.

Luxaire® Gas Heat Package Unit, Series: Optimum, Model: ZS-15, 175000 Btu/hr Gross Cooling, 172000 Btu/hr Net Cooling, 375000 Btu/hr Heating Input BTU, 300000 Btu/hr Heating Output BTU, 208/230 VAC, 15 kW Cooling Wattage, 5 hp Evaporator, 1-1/4 hp Condenser, 1725 rpm Evaporator, 1140 rpm Condenser Rotational Speed, 60 Hz, 3 ph Phase, (2) Scroll Compressor, 4430 cfm, 12.2 IEER, 10.8 EER Rating, 15 ton Tonnage, 8 Burners, 2 Heat Stages, R-410A Refrigerant, 92 dBA Decibel Rating, Belt Drive Evaporator, Direct Drive Condenser Drive, Evaporator Coil - 15.5 sq-ft Face Area, 14 Fins/in, Condenser Coil - 36 sq-ft Face Area, 18 Fins/in Coil Rating, 1 in FNPT Drain Connection, (5) 18 x 24 x 2 in Filter, 0.8 Steady State Efficiency, Steel, Galvanized, Powder-Painted, 35 to 65 deg F Rise, 125-1/4 in L x 92 in W x 48-5/8 in H

• Easy to install - Uses copper tube/aluminum fin coils in a convertible packaged cooling and gas heating line
• Flexibility - Enjoy the flexibility of a single footprint to fit most applications
• Durability - feel confident with built-in protections and certified safeties
• 5 years limited compressor warranty
• 5 years limited electric heat warranty
• 1 year limited parts warranty
• 10 years limited aluminized steel heat exchanger warranty
• Aluminized steel gas heat exchanger
• Standard static blower
• No economizer
• DSC (disconnect switch), PCO (powered convenience outlet)
• Stand alone smart equipment
• PHM (phase monitor)
• Standard refrigeration
• Standard cabinet
• CG (coil guard), standard filter
• First generation

• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Luxaire_ZW_25C00Q4B1AAA2A1_Specification_Sheet.pdf
