Luxaire® XQE06A2C1AA1C321A2 1035993

Delivering heating and cooling equipment you can trust requires an uncompromising approach to quality. Through innovative processes and rigorous testing, each Luxaire unit is built to provide consistently dependable comfort.

Luxaire® Packaged Rooftop Heat Pump Unit, Series: Eclipse, Model: XQE06, 5 ton Nominal Capacity, 58512 Btu/hr Gross Cooling, 57000 MBH Net Cooling BTU, 208/230 VAC, 2.4, 2.9 hp Indoor Fan, 1/2 hp Outdoor Fan, 60 Hz, 3 ph Phase, 1750 rpm Indoor Fan, 1100 rpm Outdoor Fan Rotational Speed, (1) Scroll Compressor, 1640 cfm, 14.5 SEER, 8.3 HSPF, 12.25 EER Rating, 3/4-14 NPT Drain Connection, R-410A Refrigerant, 1 Cool Stages, 77.78 dBA Sound Level, Belt Drive Indoor Fan, Direct Drive Outdoor Fan Drive, Indoor Coil - 7.3 sq-ft Face Area, 15 Fins/in, Outdoor Coil - 19.4 sq-ft Face Area, 17 Fins/in Coil Rating, (4) 16 x 16 x 2 in Filter, Steel, Galvanized, Powder-Painted, 74.1 in L x 48.9 in W x 40.6 in H

• Easy to install - be more competitive on rooftop replacement projects with packaged units that directly match up with competitive rooftop curbs without the need for adapters
• Flexibility - Matches up with many existing rooftop curbs
• Durability - USA manufacturing facilities ensure close quality monitoring
• 5 years limited compressor warranty
• 1 year limited parts warranty
• No heat, electric heat field installed
• No heat (cooling only)
• High static air flow
• Standard indoor and outdoor coils
• Smart equipment
• Units come standard with factory installed supply air, return air, and outdoor air temperature sensors
• Enthalpy economizer
• Powered convenience outlet
• Non-fused disconnect switch
• Second generation
