Luxaire® VS046N00H2AL82 1058972

Delivering heating and cooling equipment you can trust requires an uncompromising approach to quality. Through innovative processes and rigorous testing, each Luxaire unit is built to provide consistently dependable comfort.

Luxaire® Maxa-Miser Stand Alone Unitized Energy Recovery Ventilator, Series: V, VS046N00H Model, 3000 - 4600 cu-ft/min Air Flow, 34.5 A Minimum Circuit, 208/230 VAC, 60 Hz, 3 -Phase, 5 hp Fresh and Exhaust Air Blower, 0.17 hp at 1 PH Wheel, Net - 73% Heating and 72% Cooling Effectiveness, 1725 rev/min Fresh and Exhaust Air Blower, 1075 rev/min Wheel Speed, Belt Motor, 3 in D x 46.776 in Dia Wheel, Steel, Galvanized, Powder-Painted, 60 in L, 52.69 in W, 57.37 in H

• Performance - remove unhealthy indoor air and replace it with fresh air from outside
• Efficiency - conserve energy with efficient heat transfer
• Reliability - engineered for long-term dependability
• 59 - 66 sensible recovery
• 5 years limited parts warranty
• Segmented pies/polymeric wheel construction/media type
• 14 in air conditioner unit curb height
• High blower speed
• No selection on rooftop units
• Low ambient kit (LAK), motorized outside air (MOA) and pressure sensor (PS)
• Second generation

• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Luxaire_VD011N00H2AL52_Specification_Sheet.pdf
