The Elite® Series air conditioners are available in 6, 7.5, 10 ton (one-compressor) and 10, 12.5, 15 and 20 ton (two-compressors) nominal sizes. Reliable performance and smart engineering make the Elite® Series large split systems an ideal fit for almost any application. Units shipped completely factory assembled and wired. ELS072S4ST1G AC/6TON/460-3.
LennoxPROs® Split-System Air Handle Unit, ELS Series, Model: ELS240S4D, 20 ton Nominal Capacity, 232000 Btu/hr Cooling Capacity, 575 V, 30 A, 70 kW Wattage, 1/3 hp, 900 rpm Rotational Speed, 60 Hz, 3 ph Phase, Scroll Compressor, 13800 cfm, 12.4 EER Rating, 1 Stages, R-410A Refrigerant, 5/8 in Liquid Line, 1-1/8 in Suction Line, 89 dB Sound Level, Direct Drive, Sweat Connection, 40 A Fuse Rating, 58.7 sq-ft Face Area, 60-1/8 in L x 88-3/4 in W x 3-1/2 in H Base, Totally Enclosed Motor, 20 FPI Fins per Inch, Steel, Finish: Pre-Painted, 57-7/8 in L x 86-1/2 in W x 45-1/4 in H, Additional Information: 48-3/4 in OAH, 11 IEER Rating
| Additional Information | : | 48-3/4 in OAH, 11 IEER Rating |
| Amperage Rating | : | 30 A |
| Base Size | : | 60-1/8 in L x 88-3/4 in W x 3-1/2 in H |
| CFM Rating | : | 13800 cfm |
| Compressor Type | : | Scroll |
| Connection Type | : | Sweat |
| Cooling Capacity | : | 232000 Btu/hr |
| Dimensions | : | 57-7/8 in L x 86-1/2 in W x 45-1/4 in H |
| Drive Type | : | Direct |
| EER Rating | : | 12.4 |
| Face Area | : | 58.7 sq-ft |
| Finish | : | Pre-Painted |
| Fins per Inch | : | 20 FPI |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 40 A |
| HP Rating | : | 1/3 hp |
| Liquid Line Size | : | 5/8 in |
| Material | : | Steel |
| Model | : | ELS240S4D |
| Motor Type | : | Totally Enclosed |
| Nominal Capacity | : | 20 ton |
| Number of Stages | : | 1 |
| Phase | : | 3 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 900 rpm |
| Series | : | ELS Series |
| Sound Level | : | 89 dB |
| Suction Line Size | : | 1-1/8 in |
| Voltage Rating | : | 575 V |
| Wattage | : | 70 kW |
- Quiet and efficient operation
- Easy installation and maintenance
- Reliable performance
- Outdoor coil fans
- Copper tube/enhanced aluminum fin coil
- High-pressure switch
- Loss of charge switch
- High-capacity driers
- Refrigerant lines and service valves
- Heavy-gauge pre-painted steel cabinet
- Heavy-duty steel base rails
- Standard efficiency
- Dual circuits
