Kenmore Split-System Heat Pump, HCH9 Series, 208 to 230 V, 30 A, 1/5 hp, 60 Hz, 1 ph Phase, 659 to 765 rpm Rotational Speed, 48000 Btu/hr Cooling, 3728 to 4281 cfm, 19 SEER, Scroll Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 50 A Fuse Rating, 30.14 sq-ft Face Area, 20 FPI Coil, Tonnage: 4 ton, 67 to 72 dBA Sound Level, 2 Stages, Steel, Finish: Baked-On Powder-Coated/Galvanized, 46-7/8 in H x 35 in W x 35 in D
| Amperage Rating | : | 30 A |
| BTU Rating | : | 48000 Btu/hr Cooling |
| CFM Rating | : | 3728 to 4281 cfm |
| Coil Rating | : | 30.14 sq-ft Face Area, 20 FPI |
| Compressor Type | : | Scroll |
| Dimensions | : | 46-7/8 in H x 35 in W x 35 in D |
| Finish | : | Baked-On Powder-Coated/Galvanized |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 50 A |
| HP Rating | : | 1/5 hp |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Number of Stages | : | 2 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 659 to 765 rpm |
| SEER Rating | : | 19 |
| Series | : | HCH9 Series |
| Sound Level | : | 67 to 72 dBA |
| Tonnage | : | 4 ton |
| Voltage Rating | : | 208 to 230 V |
- Coil guard grille
- Copeland™ scroll UltraTech™ compressors on all models
- Crankcase heater factory installed
- Suction line accumulator factory installed, bi-flow filter drier included for field installation
- Bi-flow filter drier included for field installation
- Integrated solid state control with time temperature defrost
- High and low refrigerant service ports
- Discharge gas thermostat
- Copper tube/post-painted (black) aluminum fin coil
- Self-configuring installation capabilities with observer communicating wall control, compact ECM fan motor driven by integrated inverter control, outdoor temperature sensor factory installed
- Outdoor temperature sensor factory installed
- Ball bearing PSC fan motors on all models
- High performance compressor sound shield standard
- Isolation compressor grommets
- Easy-to install and service
- Coated, weather-resistant cabinet screws
- Coated inlet grille with 3/8 in grille spacing for extra protection
- Corner posts for extra strength and style
- 22.4 A rated load, 96 A locked rotor compressor, 2 A full load fan
Specification Sheet
