Johnson Controls Ignition Control, Series: G770, 24 VAC, 0.2 A, 60 Hz, 2 A Continuous, 5 A Inrush Main Valve and Pilot Valve Contact Rating, 95% RH Non-Condensing Humidity Rating, -40 to 70 deg C
| Amperage Rating | : | 0.2 A |
| Contact Rating | : | 2 A Continuous, 5 A Inrush Main Valve and Pilot Valve |
| Frequency Rating | : | 60 Hz |
| Humidity Rating | : | 95% RH Non-Condensing |
| Series | : | G770 |
| Temperature Rating | : | -40 to 70 deg C |
| Voltage Rating | : | 24 VAC |
- Indirect ignition
- High voltage spark, capacitive discharge ignition source
- Flame rectification detection
- Integral and remote detection
- 0.15 mA flame current
- 0.8 sec max flame failure response time
- 2.5 mm spark gap
- 4 sec purge time
- 120 sec trial for ignition time
- 1/4 in spade wiring connections
- 100% locknut
