Honeywell Globe Valve, 2-1/2 in Nominal, FNPT Connection, 250 lb/sq-in at 100 deg F Water, 217 lb/sq-in at 250 deg F Water, 15 lb/sq-in Steam Safe Operating, 20 lb/sq-in Differential Close-Off Pressure, Pressure Class: 150, 2-Way -Port/Way, Red Brass Body, Brass Seat, Stainless Steel Stem, Teflon Disc, Teflon and Nitrile Packing Material, 40 - 337 deg F Fluid, 1-5/8 in W x 23 in H x 5-5/8 in D
| Body Material | : | Red Brass |
| Connection Type | : | FNPT |
| Dimensions | : | 1-5/8 in W x 23 in H x 5-5/8 in D |
| Disc Material | : | Teflon |
| Nominal Size | : | 2-1/2 in |
| Number of Ports/Ways | : | 2-Way |
| Packing Material | : | Teflon and Nitrile |
| Pressure Class | : | 150 |
| Pressure Rating | : | 250 lb/sq-in at 100 deg F Water, 217 lb/sq-in at 250 deg F Water, 15 lb/sq-in Steam Safe Operating, 20 lb/sq-in Differential Close-Off |
| Seat Material | : | Brass |
| Stem Material | : | Stainless Steel |
| Temperature Rating | : | 40 - 337 deg F Fluid |
- Direct acting
- High pressure steam models with stainless steel trim
- Spring loaded, self-adjusting packing
- Stainless steel stem prevents corrosion
- Valve designs provide equal percentage characteristics of flow for close control of water and linear characteristic of flow for close control of steam or chilled water
- Valves utilize direct mounting, electric or pneumatic linear valve actuators, Q5001 linkage with Modutrol motor or Q5020/Q5022A linkages with direct coupled rotary actuators to operate the valve
- 1-3/8 in bonnet
- Stem down to close valve action
- Chilled or hot water with upto 50% glycol controlled fluid
- Equal percentage flow characteristic
- 3/4 in stem travel
- Brass plug
- 0.05% of Cu seat leakage
