Honeywell Low Voltage Cable, 2 Conductors, 300 V, 18 AWG Conductor, Solid/Stranded: Stranded, Copper Conductor, 19 x 0.0092 in Strands, Polypropylene Insulation, PVC, 0.006 in Insulation Thickness, 0.015 in Jacket Thickness, 6.5 Ohm, 35 pF/ft, 42 Ohm Impedance, Black/Red Insulation, 2-1/2 in Lay Length, Gray, -20 to 60 deg C, 0.154 in Outside Dia, 250 ft Length, Additional Information: Aluminum/Mylar Shield
| Additional Information | : | Aluminum/Mylar Shield |
| Capacitance | : | 35 pF/ft |
| Color | : | Gray |
| Conductor Material | : | Copper |
| Conductor Size | : | 18 AWG |
| Impedance | : | 42 Ohm |
| Insulation Color | : | Black/Red |
| Insulation Material | : | Polypropylene |
| Insulation Thickness | : | 0.006 in |
| Jacket Material | : | PVC |
| Jacket Thickness | : | 0.015 in |
| Lay Length | : | 2-1/2 in |
| Length | : | 250 ft |
| Number of Conductors | : | 2 |
| Outside Diameter | : | 0.154 in |
| Resistance | : | 6.5 Ohm |
| Solid/Stranded | : | Stranded |
| Strands | : | 19 x 0.0092 in |
| Temperature Rating | : | -20 to 60 deg C |
| Voltage Rating | : | 300 V |
- 24 AWG 7/32 tinned copper drain wire
- UL 1685 vertical tray
Specification Sheet
