Fieldpiece SC460 1058462
  1. pin-int

Fieldpiece SC460 1058462

Fieldpiece SC460 Clamp Meter, 600 V, 400 A, 50 MOhm, 1.2 in Jaw, 10 to 400 Hz, Backlit Display

  • Manufacturer: Fieldpiece Instruments
  • Brand Name: Fieldpiece
  • Part Number: 1058462
  • MPN: SC460
  • UPC: 872641003234
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Availability

Fieldpiece Clamp Meter, 600 V, 400 A, 50 MOhm Resistance, 1.2 in Jaw, 10000, 10 to 400 Hz, Backlit Display, 2% AC Current Accuracy, 0.5%, 1.2% Voltage Accuracy, CAT III 600 V, 9 V, 32 to 122 deg F Operating, 10000 uF, 3% Capacitance Accuracy, 1% DC Current Accuracy, 1% Resistance Accuracy, 0.01 A, 0.0001 V, 0.01 Ohm, 0.00001 uF Resolution, +/-1 deg F Temperature Accuracy, -58 to 2372 deg F, Additional Information: 100 hr Battery Life, Alkaline Battery Type

AC Current Accuracy      :      2 %
Additional Information      :      100 hr Battery Life, Alkaline Battery Type
Amperage Rating      :      400 A
Capacitance Accuracy      :      3 %
Capacitance      :      10000 uF
Counts      :      10000
DC Current Accuracy      :      1 %
Display Type      :      Backlit
Frequency Rating      :      10 to 400 Hz
Jaw Capacity      :      1.2 in
Operating Temperature      :      32 to 122 deg F
Power Supply      :      9 V
Resistance Accuracy      :      1 %
Resistance      :      50 MOhm
Resolution      :      0.01 A, 0.0001 V, 0.01 Ohm, 0.00001 uF
Safety Rating      :      CAT III 600 V
Temperature Accuracy      :      +/-1 deg F
Temperature Rating      :      -58 to 2372 deg F
Voltage Accuracy      :      0.5%, 1.2%
Voltage Rating      :      600 V
  • Job Link mobile system capability via JL2 transmitter: send and save electrical measurements to Job Link mobile system app via the JL2 long range transmitter for professional reporting, plus, calculate power (kW) and system efficiency (EER and SEER) for in D understanding of system performance in real world conditions
  • Electrical testing for HVACR - true RMS readings through the clamp or leads, capture starting amps with Inrush
  • Rugged dual display - broad temperature range tolerance allows for testing in freezers and on rooftops
  • Capacitance - test motor start and run capacitor, determine when a capacitor needs to be replaced
  • Wireless testing send measurements to the Job LinkTM mobile system app via JL2 transmitter or view measurements from other compatible tools (ET2W, EH4W, SC57, LT17AW, SC460, SC660) across the jobsite LIVE
  • Magnetic hanger - hanging strap flips out to keep the meter locked in place
  • Trusted temperature: reliable temperature in fast changing environments
  • Hold/max/min
  • High voltage LED and beeper warning
  • Non contact voltage LED and beeper
  • Continuity LED and beeper
  • Diode test
  • Easy temperature calculations
  • Frequency (Hz) through the clamp
  • Low ohm range for motor windings
  • Auto power-off
  • NIST traceable
  • Test 3-Phase power test - conveniently test phase rotation without carrying around an extra meter or extra lead, with the included alligator test lead connected to L1, you can determine phase rotation with one hand
