Crosby 3M4 HSL-36-C 1016953
Crosby 3M4 HSL-36-C Direct Spring Safety Valve, HSL Style, 3 x 4 in Nominal, Flanged Connection, 725 psig Pressure
- Manufacturer: Emerson Electric Co
- Brand Name: Crosby
- Part Number: 1016953
- MPN: 3M4 HSL-36-C
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Direct spring safety valves that provide comprehensive overpressure protection for ASME boiler and pressure vessel code section I and section VIII steam safety applications.
Crosby Direct Spring Safety Valve, H Series, HSL Style, 3 x 4 in Nominal, Flanged Connection, 725 psig, Pressure Class: 300 lb, 3.955 sq-in Orifice, Carbon Steel Body, Stainless Steel Disc, Iron Handle, 750 deg F, 33-9/16 in H, Additional Information: Lift Lever
| Additional Information | : | Lift Lever |
| Body Material | : | Carbon Steel |
| Connection Type | : | Flanged |
| Dimensions | : | 33-9/16 in H |
| Disc Material | : | Stainless Steel |
| Handle Material | : | Iron |
| Nominal Size | : | 3 x 4 in |
| Orifice Size | : | 3.955 sq-in |
| Pressure Class | : | 300 lb |
| Pressure Rating | : | 725 psig |
| Series | : | H Series |
| Style | : | HSL |
| Temperature Rating | : | 750 deg F |
- ASME/NB certified capacities for steam
- Set and tested on steam
- Restricted lift for customized capacity
- Long service life
- Low maintenance
- Two-ring set pressure and blowdown control
- ISOFLEX seat tightness up to 93%
- For seat tightness greater than 93% consult factory
Instruction/Installation Manual
