Carrier® heat pumps with Puron® refrigerant provide a collection of features unmatched by any other family of equipment. The 25HPB6 has been designed utilizing Carrier® Non-ozone depleting Puron® refrigerant. This product has been designed and manufactured to meet energy STAR® criteria for energy efficiency when matched with appropriate coil components. Refer to the combination ratings in the AHRI Directory for system combinations that meet energy STAR® guidelines.
Carrier® Heat Pump, Performance™ Series, Model: 25HPB6, 208/230 V, 11.9 A, 1/12 hp, 60 Hz, 1 ph Phase, 810 rpm Rotational Speed, 23000 Btu/hr, 3223 cfm, 13 EER Rating, 16 SEER, 8.5 HSPF, Sweat Connection, Scroll Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 5/8 in Suction Line, 25 A Fuse Rating, Direct Drive, Tonnage: 2 ton, 67 dBA Sound Level, 1 Stage, Rooftop Mounting, Steel, Finish: Baked Enamel-Coated/Galvanized, -10 to 66 deg F, 32-1/16 in H x 35 in W, Additional Information: TXV Control
| Additional Information | : | TXV Control |
| Amperage Rating | : | 11.9 A |
| BTU Rating | : | 23000 Btu/hr |
| CFM Rating | : | 3223 cfm |
| Compressor Type | : | Scroll |
| Connection Type | : | Sweat |
| Dimensions | : | 32-1/16 in H x 35 in W |
| Drive Type | : | Direct |
| EER Rating | : | 13 |
| Finish | : | Baked Enamel-Coated/Galvanized |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 25 A |
| HP Rating | : | 1/12 hp |
| HSPF Rating | : | 8.5 |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Model | : | 25HPB6 |
| Mounting Type | : | Rooftop |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 810 rpm |
| SEER Rating | : | 16 |
| Series | : | Performance™ Series |
| Sound Level | : | 67 dBA |
| Suction Line Size | : | 5/8 in |
| Temperature Rating | : | -10 to 66 deg F |
| Tonnage | : | 2 ton |
| Voltage Rating | : | 208/230 V |
- Microtube Technology™ refrigeration system
- System supports Thermidistat™ or standard thermostat controls
- Non-ozone depleting Puron® refrigerant
- Front-seating service valves
- Internal pressure relief valve
- Internal thermal overload
- High pressure switch
- Loss of charge switch
- Balanced refrigeration system for maximum reliability
- WeatherArmor™ protection package-solid, durable sheet metal construction, steel louver coil guard, baked-on, complete outer coverage, powder paint
