BELIMO® Electronic Zone Valve, Model: Z3ZN0032, 1/2 in Nominal, FNPT Connection, 3-Way Ways/Position, 300 psi Body, 30 psi Close-Off, 3.5 Cv Flow Coefficient (Cv), Stainless Steel Stem, EPDM Seat, EPDM Seal, Forged Brass, On-Off Actuator, NEMA 1, IP20 Enclosure, 7 VA Power Consumption, Hot or Chilled Water, 50% Glycol Service, NC, 24 VAC +/-10% at 50/60 Hz, 6.5 W, 32 to 212 deg F Water, 32 to 104 deg F Ambient, 4 in L x 2.36 in W x 4.76 in H
| Actuator Type | : | On-Off |
| Configuration | : | NC |
| Connection Type | : | FNPT |
| Dimensions | : | 4 in L x 2.36 in W x 4.76 in H |
| Enclosure Type | : | NEMA 1, IP20 |
| Flow Coefficient (Cv) | : | 3.5 Cv |
| Material | : | Forged Brass |
| Model | : | Z3ZN0032 |
| Nominal Size | : | 1/2 in |
| Number of Ways/Position | : | 3-Way |
| Power Consumption | : | 7 VA |
| Power Rating | : | 6.5 W |
| Pressure Rating | : | 300 psi Body, 30 psi Close-Off |
| Seal Material | : | EPDM |
| Seat Material | : | EPDM |
| Service Type | : | Hot or Chilled Water, 50% Glycol |
| Stem Material | : | Stainless Steel |
| Temperature Rating | : | 32 to 212 deg F Water, 32 to 104 deg F Ambient |
| Voltage Rating | : | 24 VAC +/-10% at 50/60 Hz |
- Spring return normally close action
- 18 in standard wire lead electrical connection
- Less than 35 dB noise level (motor)
- Motor, 20 to 40 sec running time, fail safe 5 sec
- UL94-5VB housing material
- Open close control-type
- 90 deg angle of rotation
- Maintenance-free service
- Position indication integrated into lever
- Manual override lever
