ARMSTRONG AIR® BCE7S60MA4X 1061361
ARMSTRONG AIR® OMNIGUARD™ 7 Series BCE7S BCE7S60MA4X Multi-Position Enhanced Air Handler With 2-Piece Platform, 6.9 A
- Manufacturer: Lennox International
- Brand Name: ARMSTRONG AIR®
- Part Number: 1061361
- MPN: BCE7S60MA4X
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
The ARMSTRONG AIR® full line of heat pumps is the perfect example of what happens when you set out to be the best. Quiet, energy efficient and made with pride by people who know quality, ARMSTRONG AIR® units represent the premium choice of HVAC professionals throughout North America.
ARMSTRONG AIR® OMNIGUARD™ Multi-Position Enhanced Air Handler, 7 Series, Model: BCE7S, 5 ton Nominal Capacity, 25 kW Heating, 85300 Btu/hr, 208/230 VAC, 6.9 A, 1 hp, 60 Hz, 1 ph Phase, Horizontal Right/Left, Upflow/Downflow, R-410A Refrigerant, 7/8 in Liquid Line, 3/8 in Suction Line, 20 x 24 x 1 in Filter, 1 Stages, Efficient ECM Variable Speed Motor, Steel, Finish: Baked Polyester Painted, 24-5/8 in L x 21-1/4 in W x 62-1/2 in H, Additional Information: Variable Speed Communicating
| Additional Information | : | Variable Speed Communicating |
| Amperage Rating | : | 6.9 A |
| BTU Rating | : | 85300 Btu/hr |
| Configuration | : | Horizontal Right/Left, Upflow/Downflow |
| Dimensions | : | 24-5/8 in L x 21-1/4 in W x 62-1/2 in H |
| Filter Size | : | 20 x 24 x 1 in |
| Finish | : | Baked Polyester Painted |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1 hp |
| Heating Capacity | : | 25 kW |
| Liquid Line Size | : | 7/8 in |
| Material | : | Steel |
| Model | : | BCE7S |
| Motor Type | : | Efficient ECM Variable Speed |
| Nominal Capacity | : | 5 ton |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Series | : | 7 Series |
| Suction Line Size | : | 3/8 in |
| Voltage Rating | : | 208/230 VAC |
- Shipped in one-piece, but may be disassembled into two separate pieces for ease of installation
- No external screw heads on the sides of the unit to fit in tight spaces
- Thick foil faced insulation
- Improved gasketing on doors for better fit
- Filter rack with thumb screws for easy access and removal
- Baked polyester paint finish over galvanized steel for maximum durability
- Thick rubber gaskets between each section insure tight seal when converted to downflow
- High strength, UV and heat-resistant polymer drain pan designed for corrosion resistance
- Anti-microbial polymer drain pan built-to resist mold and mildew growth
- 2% or less air leakage
- Omniguard™ total corrosion protection technology designed coil
- Enhanced tube and fin coil design featuring MHT™ Technology
- Lanced fins for maximum heat transfer
- Factory tested for leak-proof construction and precharged with nitrogen holding charge
- Communicating control enabled
- Thermostat flexibility - works with the Comfort Sync® T-Stat or a conventional 24 V T-Stat
- Self-diagnostics saves last 10 fault codes regardless of power interruption
