Appleton™ Receptacle, 120 to 600 VAC, 100 A, 50 to 400 Hz, 4 Pole, 3 Wires, 3R, 4, 4X, NEMA 3, Grounding Grounding Type, Wire Terminal, Aluminum Housing, Epoxy Powder-Coated, Additional Information: Dead-End or Feed-Thru Mounting Box Entry
| Additional Information | : | Dead-End or Feed-Thru Mounting Box Entry |
| Amperage Rating | : | 100 A |
| Finish | : | Epoxy Powder-Coated |
| Frequency Rating | : | 50 to 400 Hz |
| Grounding Type | : | Grounding |
| Housing Material | : | Aluminum |
| NEMA Rating | : | 3R, 4, 4X, NEMA 3 |
| Number of Poles | : | 4 |
| Number of Wires | : | 3 |
| Terminal Type | : | Wire |
| Voltage Rating | : | 120 to 600 VAC |
- Circuit breaking in 30, 60, 100 and 200 A units, any arcing created as line and load terminals disengage is safely confined deep within terminal cavities, plugs may be withdrawn in an emergency under full-rated loads without separate disconnect switch
- Only plugs and receptacles of same style, number of poles and ampere rating can be used together
- Locking screw and slot prevents plug cable collar from #8221, backing off #8221
- Controlled length contacts ensure that ground makes first and breaks last for added safety
- Contacts exert constant pressure along entire contact surface and provide electrical continuity
- Insulating blocks provide greatest dielectric and mechanical strength and lowest arc tracking
- Neoprene bushing compressed by cable collar prevents entrance of water
- Bushing is highly resistant to hydrocarbon deterioration and is self-extinguishing
- 30, 60, 100 and 150 A Powertite™ plugs also suitable for classified locations when used with Appleton™ EBR, EBRH, JBR, MD2SR, FSQC, ID2SR or DBR hazardous interlocked receptacles
