Amana® AH093A35MA 1051289
Amana® AH Series AH093A35MA Heat Pump, 9300 Btu/hr Cooling, 10700 Btu/hr Heating BTU, 208 to 230 V, 2792 to 3416 W
- Manufacturer: Daikin Comfort Technologies
- Brand Name: Amana®
- Part Number: 1051289
- MPN: AH093A35MA
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Amana® Heat Pump, AH Series, 208 to 230 V, 4.6 to 4.8 A Cooling, 13.4 to 14.8 A Electric Heater, 2792 to 3416 W, 60 Hz, 1 ph Phase, 9300 Btu/hr Cooling, 10700 Btu/hr Heating, 310 cfm, 10 EER Rating, R-410A Refrigerant, 20 A Fuse Rating, 2.2 pt/hr Dehumidification, 15-3/8 in H x 22-5/8 in W x 24 in D
| Amperage Rating | : | 4.6 to 4.8 A Cooling, 13.4 to 14.8 A Electric Heater |
| BTU Rating | : | 9300 Btu/hr Cooling, 10700 Btu/hr Heating |
| CFM Rating | : | 310 cfm |
| Dehumidification | : | 2.2 pt/hr |
| Dimensions | : | 15-3/8 in H x 22-5/8 in W x 24 in D |
| EER Rating | : | 10 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| Phase | : | 1 ph |
| Power Rating | : | 2792 to 3416 W |
| Refrigerant Type | : | R-410A |
| Series | : | AH Series |
| Voltage Rating | : | 208 to 230 V |
- 3.5 kW heater capacity
- Slide-out for easy installation and service accessibility chassis
- Condensate drain spout on the wall sleeve
- Top discharge air
- 100% full factory run test on all units for high reliability and dependability
- Ball bearing fan motors that are reliable, start quickly and run quietly
- Easy-access slide out filter has a permanent polypropylene filter mesh that is easy to remove and clean
- Hydrophilic coating on evaporator and condenser coils on all models which allows better moisture removal, increased airflow, increased heat exchange, higher efficiencies and longer compressor life
- Solid bottoms on outer cases for full seal - thru-the-wall installation
- 6 ft LCDI power cord, perpendicular plug
- High/low two-speed fan
