AIREASE® 4SCU16LE142P 1040774
AIREASE® OMNIGUARD™ Pro Series 4SCU16LE142P Louvered Enhanced Split System Air Conditioner, 208 to 230 VAC, 39500 Btu/hr
- Manufacturer: Lennox International
- Brand Name: AIREASE®
- Part Number: 1040774
- MPN: 4SCU16LE142P
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Offering 16 SEER efficiency, the 4SCU16LS saves you money every month and may qualify for local utility rebates. Because it operates at two different speeds, this air conditioner provides enhanced performance with improved control over temperature and humidity for healthier air throughout your home. Plus, the 4SCU16LE constantly monitors itself for optimum performance and complete peace of mind.
AIREASE® OMNIGUARD™ Louvered Enhanced Split System Air Conditioner, Pro Series, Model: 4SCU16LE, 42 ton Nominal Capacity, 39500 Btu/hr, 208 to 230 VAC, 35 A, 1/6 hp, 825 rpm Rotational Speed, 60 Hz, 1 ph Phase, High Efficiency Scroll Compressor, 11.2 EER Rating, 16 SEER, 1 Stages, R-410A Refrigerant, 3/8 in Liquid Line, 7/8 in Suction Line, 77 dBA Sound Level, Grommet Mounting, 0 to 125 deg F, Steel, Finish: Baked Polyester Painted, 37.75 in H x 29.38 in W x 31.25 in D
| Amperage Rating | : | 35 A |
| BTU Rating | : | 39500 Btu/hr |
| Compressor Type | : | High Efficiency Scroll |
| Dimensions | : | 37.75 in H x 29.38 in W x 31.25 in D |
| EER Rating | : | 11.2 |
| Finish | : | Baked Polyester Painted |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/6 hp |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Model | : | 4SCU16LE |
| Mounting Type | : | Grommet |
| Nominal Capacity | : | 42 ton |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 825 rpm |
| SEER Rating | : | 16 |
| Series | : | Pro Series |
| Sound Level | : | 77 dBA |
| Suction Line Size | : | 7/8 in |
| Temperature Rating | : | 0 to 125 deg F |
| Voltage Rating | : | 208 to 230 VAC |
- Grommet-mounted compressor for quiet operation
- Internally protected against high temperature motor overload conditions
- Heavy-duty compressor sound blanket for quiet operation
- Full metal louvered panel with two screws to remove for ease of coil cleaning and service
- Corner-mounted controls for easy service
- Rounded corners for safety and attractive, clean appearance
- Baked polyester paint finish over galvanized steel for maximum durability
- Stamped, one-piece top
- External gauge ports for easy service
- Omniguard™ total corrosion protection technology designed coil
- Enhanced tube and fin coil design featuring MHT™ Technology
- Lanced fins for maximum heat transfer
- Every coil factory tested for leak-proof construction
- Raised coil prevents debris from impeding airflow
- 45 deg offset gauge ports for easy service
- Factory installed high and low pressure switches
- Thread-on pressure switches with Schrader core for simple, quick replacement
- Filter drier shipped loose for installation flexibility
- Fan orifice for smoother airflow and sound level reduction
- Charged for 15 ft of line set
