The Russell all-temp B is the original low profile unit cooler that has established an industry standard as being the all-purpose design for walk-in coolers, freezers and other applications. They feature an air draw through design offering air, electric and hot gas defrost models. Rust-free, heavy gauge, textured Aluminum casing is lightweight yet durable. Each fan section is baffled to prevent short cycling of the air. The unit is designed to mount flush to the ceiling and meets all NSF requirements. Slotted hangers are provided for easy installation. Drain fittings are installed in the horizontal position to gain more usable headroom in low ceiling applications. The end panels now are hinged to open up out for easy access to both the piping and electrical ends. Optional expansion valves can be conveniently installed inside the cabinet.
Russell Unit Cooler, Series: All-Temp Series, 115 V, 0.8/1 A, 1/20 hp HP Rating, 60 Hz, 1 ph, 4800 Btu/hr, 800 cfm CFM Rating, NPT, 1/2 in, 12 in Fan Size, 1 Number of Fans, PSC Motor, 6 FPI Fins per Inch, Flush to Ceiling Mount, Aluminum, 35 deg F, 15 in H x 15-1/4 in W
| Amperage Rating | : | 0.8/1 A |
| BTU Rating | : | 4800 Btu/hr |
| CFM Rating | : | 800 cfm |
| Connection Size | : | 1/2 in |
| Connection Type | : | NPT |
| Dimensions | : | 15 in H x 15-1/4 in W |
| Fan Size | : | 12 in |
| Fins per Inch | : | 6 FPI |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/20 hp |
| Material | : | Aluminum |
| Motor Type | : | PSC |
| Mounting Type | : | Flush to Ceiling |
| Number of Fans | : | 1 |
| Phase | : | 1 ph |
| Series | : | All-Temp Series |
| Temperature Rating | : | 35 deg F |
| Voltage Rating | : | 115 V |
- The embossed aluminum casing is lightweight yet durable
- Each fan section is baffled to prevent short cycling of the air
- The unit is designed to mount flush to the ceiling and meets all NSF requirements
- The top pan is slotted for simple installation
- Drain fittings are installed in the bottom of the drain pan for easy field connection and the drain fitting can be quickly replaced without replacing the entire drain pan
- The end panels can now be slid out from the front of the unit for easy serviceability from the front or end of the unit
- Copper hairpins are staggered and mechanically expanded into corrugated aluminum fins and tube sheets to achieve maximum heat transfer
- Heavy-duty 12 in aluminum fans are balanced to provide vibration-free operation
- Our low throw black plastic fan guards provide an optimal air pattern
- The optional epoxy resin high throw fan guard moves air upto 25 ft
- All components are factory wired to convenient screw-type terminal strips
- A large compartment is supplied internal to the unit for all electrical components and is easily accessible by opening the slide out end panel
- Air defrost models (prefix "AA") are designed for use in coolers of 35 deg F and warmer
