DeWALT® 02316-PWR 1078120

The Wall-Dog™ is an all steel, one piece screw anchor, which features high-profile threads for easy fastening into wallboard and other masonry base materials. The deep cutting, corkscrew like threads provide for smooth entry and a powerful hold. When removed, the Wall-Dog™ leaves a much smaller hole than toggles or other systems. For aesthetic appearances, the Wall-Dog™ is available in several color finishes and head styles. For fastening into wallboard or wood, no pre-drilling is required the anchor is inserted through the fixture and screwed in with an ordinary Phillips screwdriver. Fastening into concrete, hollow or grout filled concrete masonry, brick and plaster requires a pre-drilled hole using a 3/16 in ANSI bit. Typical applications include lightweight fixtures, drapery supports, as well as electrical, telephone and cable accessories.

DeWALT® Universal Light-Duty Anchor, 1/4 in Diameter, 1-1/4 in Length, 3/4 in Minimum Embedment, 3/16 in Drill, Pan Head, 1018 Grade, 350 lb Tensile Strength, 1030 lb Shear Strength, 1/2 in Fixture Thickness, 700 lb Load Rating, Carbon Steel, Finish: Zinc-Plated, Silver

• Installs in a variety of base materials
• When removed the anchor leaves a much smaller hole than toggles or other systems
• Heat treated point penetrates wood studs and thin metal
• No pilot hole required for wallboard
• Installs directly through fixtures into wallboard no second step or hole spotting required
• Thread design prevents spinning and stripping
• Several finished head styles to match application
• Can be easily backed out of hole

• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/DeWALT_02316_PWR_Specification_Sheet.pdf
