Rheem® Electric Heat Package Unit, Series: RRNL, Classic, Model: B042JK10, 42000 Btu/hr Cooling, 100000 Btu/hr Heating Input BTU, 208/230 VAC, 27 A, 12.31 kW Cooling Wattage, 1/3 hp Outdoor Fan, 1/2 hp Indoor Fan, 1075 rpm Outdoor Fan, 1075 rpm Indoor Fan Rotational Speed, 60 Hz, 1 ph Phase, (1) Scroll Compressor, 1400 cfm, 11.2 EER Rating, 13 SEER, 3.5 ton Tonnage, 5 Burners, 1 Stage, R-410A Refrigerant, 76 dBA Decibel Rating, Electric Ignition, Direct Drive, Outdoor Coil - 16.65 sq-ft Face Area, 22 Fins/in, Indoor Coil - 7.39 sq-ft Face Area, 15 Fins/in Coil Rating, 3/4 in Drain Connection, (1) 1 x 24 x 24 in Filter, 47-1/2 in L x 52-7/16 in W x 41 in H

• All models feature scroll compressors for maximum efficiency and quiet operation
• Louvered condenser compartment for protecting the coil against yard hazards and/or weather extremes
• One-piece top with a deep flange to help keep water out of the unit
• Supply and return air openings feature a 1 in tall flange to prevent water migration into the ductwork
• Access panels have "weep holes" and channels to further help manage water run-off
• Side and down discharge options available on all models, all models are shipped ready for horizontal application
• Easily accessible blower section complete with slide-out blower, the RRRL comes standard with variable speed motor with adjustable air flow in heating and cooling, the variable speed motor also comes with a interface that allows for dehumidification when used in continuous humidistat, the variable speed system is capable of 1 in external static
• Refrigerant connections are conveniently located for easy service diagnostics
• Condenser and evaporator coils feature enhanced fins for better heat transfer and rifled copper tubing for greater efficiency
• Inside the easily accessible furnace compartment is the draft inducer motor, this is specially designed for quiet reliable operation, in addition to the draft inducer motor, the in-shot gas burners and manifold efficiently regulate the flow of gas for combustion, these new gas/electric units also feature direct-spark ignition and remote flame sensors for added reliability and efficiency
• All units feature an internal trap on the condensate line eliminating the need for installing an onsite external trap
• Easily accessible control box
• One-point wiring simplifies installation
• Gas/electric package units feature a tubular heat exchanger design, tubular heat exchangers are more efficient and durable than older-style clamshell heat exchangers
• The heat exchanger is backed by a 10 year limited warranty
• Thermal expansion valve standard on all models for superior superheat control, reliability and energy efficiency at all operating conditions
• Filter drier standard on all models
• Rugged base rail included for improved installation and handling
• Complete factory charged, wired and run tested
• Molded compressor plugs
