Rheem®_DEL_2024_MAR_19_11_57_08 RKQN-C048CM13EEGJ 1064843
Rheem® RKQN-C, Classic RKQN-C048CM13EEGJ C048CM13 Electric Heat Package Unit, 208/230 VAC, 22 A, 1600 cfm, 4 ton
- Manufacturer: Rheem Manufacturing_DEL_2024_MAR_19_11_56_58
- Brand Name: Rheem®_DEL_2024_MAR_19_11_57_08
- Part Number: 1064843
- MPN: RKQN-C048CM13EEGJ
- UPC: 662021445767
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Rheem® Electric Heat Package Unit, Series: RKQN-C, Classic, Model: C048CM13, 48000 Btu/hr Cooling, 135000 Btu/hr Heating Input BTU, 208/230 VAC, 22 A, 14.07 kW Cooling Wattage, 1/3 hp Outdoor Fan, 3/4 hp Indoor Fan, 1075 rpm Outdoor Fan, 1725 rpm Indoor Fan Rotational Speed, 60 Hz, 3 ph Phase, (1) Scroll Compressor, 1600 cfm, 12.5 EER Rating, 15 SEER, 4 ton Tonnage, 6 Burners, 1 Stage, R-410A, HFC Refrigerant, 78 dBA Decibel Rating, Electric Ignition, High Static Belt Drive, Outdoor Coil - 16.4 sq-ft Face Area, 23 Fins/in, Indoor Coil - 4.8 sq-ft Face Area, 20 Fins/in Coil Rating, 3/4 in Drain Connection, (1) 1 x 16 x 25 in Filter, Steel, Galvanized, Baked Enamel-Coated, 125 deg F Ambient, 76 in L x 48-1/2 in W x 35-1/2 in H
| Amperage Rating | : | 22 A |
| CFM Rating | : | 1600 cfm |
| Coil Rating | : | Outdoor Coil - 16.4 sq-ft Face Area, 23 Fins/in, Indoor Coil - 4.8 sq-ft Face Area, 20 Fins/in |
| Compressor Type | : | (1) Scroll |
| Connection Type | : | 3/4 in Drain |
| Decibel Rating | : | 78 dBA |
| Dimensions | : | 76 in L x 48-1/2 in W x 35-1/2 in H |
| Drive Type | : | High Static Belt |
| EER Rating | : | 12.5 |
| Filter Size | : | (1) 1 x 16 x 25 in |
| Finish | : | Galvanized, Baked Enamel-Coated |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp Outdoor Fan, 3/4 hp Indoor Fan |
| Ignition Type | : | Electric |
| Input BTU Rating | : | 48000 Btu/hr Cooling, 135000 Btu/hr Heating |
| Material | : | Steel |
| Model | : | C048CM13 |
| Number of Burners | : | 6 |
| Number of Stages | : | 1 |
| Phase | : | 3 ph |
| Refrigerant Type | : | R-410A, HFC |
| Rotational Speed | : | 1075 rpm Outdoor Fan, 1725 rpm Indoor Fan |
| SEER Rating | : | 15 |
| Series | : | RKQN-C, Classic |
| Temperature Rating | : | 125 deg F Ambient |
| Tonnage | : | 4 ton |
| Voltage Rating | : | 208/230 VAC |
| Wattage | : | 14.07 kW Cooling |
- Complete factory charged, wired and run tested
- Scroll compressors with internal line break overload and high-pressure protection
- Convertible air flow
- TXV refrigerant metering device
- High pressure and low pressure/loss of charge protection standard on all models
- Solid core liquid line filter drier
- One-slab, micro-channel designed evaporator coil facilitates easy cleaning for maintained high efficiencies
- Easily removable filter, blower, gas heat and compressor/control access panels permits prompt service
- Powder paint finish meets ASTMB117 steel-coated on each side for maximum protection, G90 galvanized
- One-piece top cover and one-piece base pan with drawn supply and return opening for superior water management
- Externally mounted refrigerant gauge ports for easy service diagnostics
- Easy to install plug-in, slip-in, 100% fully modulating economizer
- Forkable base rails for easy handling and lifting, one-point electrical and gas connections
- High performance belt drive motor with variable pitch pulleys and quick adjust belt system
- Permanently lubricated evaporator, condenser and gas heat inducer motors
- Condenser motors are internally protected, totally enclosed with shaft down design
- 1 in filter standard with slide-out design, will accept 2 in filter
- One-stage gas valve, direct spark ignition and induced draft for efficiency and reliability
- Improved gas heating efficiency (AFUE: 81%)
- Tubular heat exchanger for long life and induced draft for efficiency and reliability
Instruction/Installation Manual
