The Mini-Undercut+ anchor is an internally threaded, self-undercutting anchor designed for performance in cracked and uncracked concrete. Suitable base materials include post tension concrete (PT slabs), hollow core precast concrete, normal weight concrete and lightweight concrete. The Mini-Undercut+ anchor is installed into a pre drilled hole with a power tool and a setting tool. After installation a steel element is threaded into the anchor body. The result is an anchor which can provide consistent behavior at shallow embedments as low as 3/4 of an in.
DeWALT® Internally Threaded Undercut Anchor, 5/8 in Diameter, 3/4 in Length, Additional Information: 3/8 in Rod, 3/8 x 3/4 in Anchor
| Additional Information | : | 3/8 in Rod, 3/8 x 3/4 in Anchor |
| Diameter | : | 5/8 in |
| Length | : | 3/4 in |
- ANSI carbide stop bit with enlarged shoulder for accurate drill depth
- Internally threaded anchor for easy adjustment and removability of threaded rod or bolt
- Cracked concrete tested alternative to a mini drop-in anchor
- Drill and drive the anchor with one tool for fast anchor installation
Specification Sheet
