The DW088LG 12 V max green cross line laser features 12 V max lithium-ion rechargeable power tool battery platform, self-leveling cross lines and green beam laser technology. Over molded housing and IP65 are debris and water-resistant.
DeWALT® Cross Line Laser, 12 V Lithium-Ion Rechargeable Battery, 100 to 165 ft Measuring, 2 Beams, 2 Lines, +/-1/8 in Accuracy, 2 Laser Class, 515 to 535 nm, Green Laser, 18.15 in Overall Length, 12.91 in Overall Width, 6.26 in Overall Height, 1/4 in, 5/8 in Mounting Thread Diameter, Plastic Housing, Black/Yellow Housing
| Accuracy | : | +/-1/8 in |
| Housing Color | : | Black/Yellow |
| Housing Material | : | Plastic |
| Laser Class | : | 2 |
| Laser Color | : | Green |
| Measuring Range | : | 100 to 165 ft |
| Mounting Thread Diameter | : | 1/4 in, 5/8 in |
| Number of Beams | : | 2 |
| Number of Lines | : | 2 |
| Overall Height | : | 6.26 in |
| Overall Length | : | 18.15 in |
| Overall Width | : | 12.91 in |
| Power Source | : | 12 V Lithium-Ion Rechargeable Battery |
| Wavelength | : | 515 to 535 nm |
- 12 V lithium-ion rechargeable power tool battery platform for extra long run time and the convenience of rechargeable power tool batteries
- Self-leveling cross lines project bright crossing horizontal and vertical lines for various leveling and layout applications
- Four times brighter green laser technology for visibility in long range interior applications and exterior visibility
- Integrated magnetic bracket with 1/4 and 5/8 in thread rear-mounted magnets allow flush attachment to metal and steel track
- Full time pulse mode allows use with detector, maintains full brightness for visibility and extends range
- Overmolded housing and IP65 debris/water resistance
- Locking pendulum to help prevent damage to internal components
